By WildTrack
Can tracking mouse footprints give clues to climate change? Yves Vanderhaeghen speaks to the founders of WildTrack, which is pioneering technology in South Africa to track small mammals so they can tell us about disruptions to ecosystems.
Is it a mouse? A shrew? A rat? We can read a lot into the pawprints of small mammals, even signs of climate change. But they tread so lightly it’s tricky to know from faint tracks in the sand who’s passed by.
To solve the difficulty a team from WildTrack, a non-profit which uses AI, data analytics and on-the-ground expertise to protect endangered species, is pioneering technology in South Africa. It consists of laying down a patch of charcoal for an animal to step into and white paper to pick up its prints, which are then analysed and recorded in a growing database.
Founders Zoë Jewell and Sky Alibhai were recently at Telperion Nature Reserve on the border of Mpumalanga and Gauteng provinces to run a second round of trials together with their South African colleagues Nico Avenant, head of the Department of Mammalogy at the National Museum in Bloemfontein, and Marietjie Oosthuizen of the Department of Zoology and Entomology at the University of Pretoria.
Jewell and Alibhai, together with OGRC head Duncan MacFadyen and Avenant, will do a presentation on the technology at the Oppenheimer Research Conference (ORC), which takes place in Johannesburg from October 9 to 11. The presentation is titled: “A transformative tool for monitoring biodiversity using a combination of traditional ecological knowledge with leading-edge analytics and AI”.
“While we're collecting small mammal footprints across a wide range of countries, South Africa is the first place we've decided to start implementing it as a biodiversity survey,” says Jewell. Continuing, she states, "We did an initial run last year at Tswalu reserve in the Kalahari, and we repeated the process at Telperion. The idea is to set up a system which enables the recording of all small mammal species using their footprints to identify at the species level. The basic technology has already been proven in other parts of the world, but for large animals."
"WildTrack has got this project called FIT (footprint identification technology), which we've been using over a long period of time,” says Jewell. “We've been working with tigers in China; rhinos, leopard, lion in Africa. In Brazil, we work with puma and jaguar.” FIT can identify species, individuals, and their age class which guides monitoring strategies.
“Now we're applying that to small mammals, and because it's a non-invasive technique we don't need to catch or handle them,” says Jewell.
Biologists increasingly rely on non-invasive sampling techniques such as camera traps and acoustic recorders (which are also being pioneered for small mammals by Dr Haemish Melville at Telperion), as well as non-invasive genetic sampling from scat, for example. “These non-invasive techniques don't disturb or change the natural behaviour of the animals in any way, which can often provide better quality scientific data as well as enhance welfare,” says Jewell.
“So we're not actually trapping animals, except when we set up the initial database. Once that is done, we then just use the track plates to collect the footprint images from which we can identify the species. Our aim is to develop a non-invasive and cost-effective metric for monitoring biodiversity. And because small mammals are a very important part of the integrity of most ecosystems, they make a great metric for assessing the health of
ecosystems.
“What we would love to do,” she says, “is have something like our track plates go out into the field with little acoustic devices in them that will pick up sounds as well. So we'll have a wealth of information coming through about these little animals without ever having to see them or track them or disturb their natural environment.”
Computer technology is key to the process.
“To begin with,” says Jewell, “you have to develop a reference library to train the computer to know which species is which. At the moment, with the small mammals, we're in the training phase where we capture a range of species, and we have them walk over a little platform, which we have in the lab, which is a little bit of charcoal on one end and some standard shelf sticky paper."
"They walk over that, they get a little bit of charcoal on their feet, they walk over the sticky paper, they leave their footprints, and then we pick them up at the other end, put them back in the trap, and release them at the same locality they were collected. “We then have a piece of sticky paper with footprints on it, which we can attribute to the animal that we caught, so we know exactly which species it came from. And we repeat that process with all the species that we catch, and we've got 20 species at the moment. So that's a hot off the press figure,” says Jewell.
“When we've caught enough new species, and we're confident that we've got a good library, we put those through the computer using two different systems. One is a morphometric system, which allows us to take measurements from those footprints. We can identify the species that made those footprints using a customised statistical program called JMP data visualisation software. So that gives us a measure of which species is which.
“The other system that we're developing is artificial intelligence, where we'll simply take an image of the whole track plate with all the footprints on it, and we'll put that through the computer, and train it how to identify the species just from looking at those images of the footprints without having to take any measurements or any other manual intervention.
Those two approaches together will then allow us to put out these very simple little tunnels into the field with some sticky paper and charcoal, pick those up every day, and get a measure of which species are out there without any trapping or handling, or any real need for a lot of expertise in the field.”
It's easier with large animals which leave clear indentations in sand, “but the challenge with small mammals has been they're very light, and they don't leave very clear footprints in natural substrate,” says Jewell.
However, they do leave “absolutely perfect footprints on these little pieces of sticky paper, and you can put them down anywhere in the field. You can nestle them in the grass, near the small mammal runs, or in the sand.”
She shows a short video to illustrate the clarity of impressions.
Alibhai explains the footprints we’re seeing: “This is a Micaelamys namaquensis, a Namaqua rock mouse,” he says. “And you can see this lovely looking hindfoot here. I can tell you that that's a left hind foot just by looking at the arrangement of the digits: 1, 2, 3, 4, 5 - they're the tips of the fingers, and then these are the interdigital pads. And from the arrangement, you can actually tell that's a hind foot.
“And this one over here, which is a little bit more faint, is a front foot. And once you get your eye in, you begin to understand exactly the arrangement of the left and right. And then what we basically do with morphometrics, which is taking measurements from the footprint, is to assign each of those points that I've just mentioned a number, and we put that into our software, and we extract distances, angles, areas, and then we use statistics, which allows us to identify which species it is.”
While morphometrics have been used widely with other species, Alibhai says that “the actual implementation of this as a biometric survey technique is being pioneered in South Africa. It's our intention that it'll help large companies and organisations who are required to do environmental impact surveys.
It'll help them do it much more cheaply and quickly than they're currently able to. At the moment, if you want to go and survey small mammals, which everybody agrees is an important group to survey, you need to have experts in the field who can catch them, handle them, identify them, count them, and repeat this over and over and over again.”
Small mammals are excellent indicators of biodiversity disruption, says Alibhai, “because their replacement rate is very, very fast”. This means being able to measure their response to environmental change, “be it natural or man-made. For example, if a company is trying to set up a huge factory somewhere, and they want to do an environmental impact
assessment, we can use small mammals as indicators.
Go in there and do a before study, a during study, and then follow it up with an after study. It's a very simple technique, very cheap, very easy to deploy, doesn't require a great deal of expertise, doesn't require a great
deal of equipment.
Adds Jewell: "It's not only the number of species that's important. We also need to know which species. Many are indicators for different types of environmental disturbance, for example showing up if there's a negative impact or a change in predator balance,” which might show why a grassland is being destroyed by mice when their numbers explode due to a lack of predation.
Once the AI has produced a list of species, it will indicate the health of the environment. “When you start looking, you realise what incredible variety there is. And small mammals actually account for up to 40% of all mammal species in some areas,” says Jewell.
“But people don't see them,” interjects Alibhai. “They're almost invisible. But if you set up a long term study, there would be great indicators of climate change. If you look at their species distribution, and look at their numbers, that would be an indicator of climate change. Jewell stresses that local collaborators are critical in this research.
“We're not from South Africa, but a lot of our team members are. One of our objectives is to make sure that when this technique is ready for implementation, people on the ground are able to use it.” This WildTrack programme has another local connection, Oppenheimer Generations Research and Conservation, whose head, Duncan MacFadyen offered that they work at one of the OGRC sites. “So that's how we ended up at Tswalu last year and Telperion just recently. And we'll be back at Telperion in October for the 3rd phase of the project.”
The JRS Biodiversity Foundation (https://jrsbiodiversity.org/) funds this project.
“We're very lucky that we've got good colleagues in South Africa who are helping us develop it because they'll be key to making it work in South Africa. And then, hopefully, South Africa will pioneer it and then spearhead development for other regions in Africa.”
